| Frame | Uni-directional carbon mainframe, ZS56 top and bottom head tube, internal cable routing, 6061 Alloy swing arm, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| Fork | RockShox Lyrik Select, 160mm travel, 44mm offset, Linear XL, Delta RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle stealth |
| Rear shock | RockShox Super Deluxe Select, DebonAir, Fast Black coating, adjustable rebound, 230 x 57.5mm, custom tuned for Whyte |
| Headset | FSA custom headset, ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings |
| Rear hub | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole, HG freehub |
| Front hub | Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, 32 hole |
| Spokes | 14g stainless black, brass nipples |
| Rims | Whyte eMTB sleeved rims, 30mm internal width, tubeless ready, 29" front and rear |
| Tyres | Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead (front); Maxxis Minion DHR 2 WT, TR, 29 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound (rear) |
| Shift levers | SRAM Eagle 70, 12 speed |
| Front mech | N/A |
| Rear mech | SRAM Eagle 90 T-Type mechanical, 12 speed |
| Cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| Chain | SRAM Eagle 70, 12 speed |
| Crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount 36T chainring, T-Type |
| Bottom bracket | N/A |
| Seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop) |
| Seat | Whyte Custom |
| Bar | Whyte Custom 7050 alloy, 40mm rise, 35mm bar bore, 800mm wide |
| Stem | Whyte, 35mm extension, 35mm bar bore |
| Grips | Whyte Enduro lock-on |
| Front brakes | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 220mm six bolt Centreline rotor |
| Rear brakes | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 200mm six bolt Centreline rotor |
| Brakes levers | SRAM Maven Base |
| Pedals | Fibre reinforced composite platform |
| eBike motor | Avinox M2S drive unit with 150Nm maximum torque, 1300W of peak power and 250W of nominal power. Features five power mode settings including Auto and Boost. |
| eBike display | Avinox DPC100 OLED display mounted within the top tube, paired with the discrete bar mounted wireless controller. Also connects to the Avinox Ride smartphone app to give you even more insight and control at your fingertips. |
| eBike battery | Avinox 800Wh fixed battery, mounted into the frame by 2x bolts. Removeable for maintenance by removing motor. |
| eBike battery charger | Charger 4A (230V) |
| Shock, stroke, sag | 57.5mm/16mm |
| Reducer bush widths | 25mm |
| Eye to eye length | 230mm |
