Frame
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts
Fork
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, flat mount with mudguard and mounting bosses
Headset
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed cartridge bearings and front entry for cables
Rear Hub
Alloy, double sealed cartridge bearings, 12mm x 142mm thru axle, Center Lock, 32 hole
Front Hub
Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, Center Lock, 32 hole
Spokes
2.0mm, PG, black stainless, brass nipples
Rims
WTB ST i30 rims, 30mm internal width, tubeless ready, 32 hole
Tyres
Maxxis Ravager Tanwall 700 x 50c, EXO 60TPI, folding bead
Shift Levers
SRAM Apex D1, 12 Speed
Front Mech
N/A
Rear Mech
SRAM Apex Eagle, 10-52t, 12 Speed
Cassette
SRAM XG-1275, 10-52T, XD Driver
Chain
SRAM GX Eagle, Power Lock
Crankset
SRAM Apex D1, DUB Wide, 170mm, 40t chainring
Bottom Bracket
SRAM DUB BSA 68/73mm Road
Seatpost
Trans-X YSP38 dropper post, 27.2mm, Rocker remote, size specific drop (sizes XS and S: 70mm travel; sizes M and L: 90mm travel; size XL: 110mm travel).
Saddle
Whyte Custom
Handlebar
Controltech, 6061 alloy, 70mm reach, 115mm drop, 10mm rise, 16° flare, 31.8mm x 400mm wide (size XS), 420mm (size S), 440mm (size M), 460mm (size L+XL)
Stem
Whyte Alloy, +-7° rise, 60mm length (XS, S), 70mm (M, L, XL)
Grips
Whyte anti-slip, ‘cross bar tape
Front Brakes
SRAM Apex D1, Flat Mount, internal routing, 180mm rotor
Rear Brakes
SRAM Apex D1, Flat Mount, internal routing, 160mm rotor
Brake Levers
SRAM Apex D1
Pedals
Fibre reinforced composite platform
