Frame
6061 Alloy, Aluminium Front Triangle with ZS56 Head Tube, ISCG 2 Guide Mounts, proportional chainstays, Shape.it link and 148mm Boost Dropouts
Fork
Marzocchi Bomber Z1, 170mm travel, 44mm offset, air spring, Rail damper, black coating, tapered steerer, 110mm x 15mm Boost, Kabolt axle
Rear shock
Marzocchi Bomber Air piggyback shock, black coating, adjustable rebound and compression, 230 x 57.5mm, custom tuned for Whyte
Headset
ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings
Rear hub
Alloy, double sealed cartridge bearings, 12mm x 148mm Boost thru axle, MicroSpline freehub, 32 hole
Front hub
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru axle, 32 hole
Spokes
Pillar 14G, black stainless, brass nipples
Rims
WTB ST Tough i30 TCS 2.0 System, pinned joint, tubeless ready, 32 hole, 29in (front), 27.5in (rear)
Tyres
Schwalbe Magic Mary Radial 29 x 2.5in Trail, Super Soft (front); Schwalbe Magic Mary Radial 27.5 x 2.5in, Gravity casing, Soft (rear)
Shift levers
Shimano M6100 Deore, I-Spec EV, 12 speed
Rear mech
Shimano M6100 Deore, SGS, Shadow Plus, 12 speed
Cassette
Shimano CSM6100, 11-51T, black, 12 speed
Chain
KMC X12, 12 speed
Crankset
Whyte, forged two-piece cranks, direct mount, alloy 30T narrow/wide chainring, 165mm crank length, Boost, 12 speed, 55mm chainline
Bottom bracket
BSA, cartridge bearings, 73mm
Seatpost
TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop)
Seat
Whyte Custom
Bar
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide
Stem
Whyte, 35mm extension, 35mm bar bore
Grips
Whyte Enduro lock-on
Front brakes
TRP EVO Comp hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX
Rear brakes
TRP EVO Comp hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX
Brakes levers
TRP EVO Comp
