Frame
6061 Alloy, Aluminium Front Triangle with ZS56 Head Tube, ISCG 2 Guide Mounts, proportional chainstays, Shape.it link and 148mm Boost Dropouts
Fork
RockShox Lyrik Ultimate RC2 29in, 170mm travel, 44mm offset, Linear XL with ButterCups, Charger 3.2 RC2 damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear shock
RockShox Super Deluxe Ultimate RC2T, DebonAir+, Fast Black coating, adjustable rebound, low and high speed compression adjustment, 230 x 57.5mm, custom tuned for Whyte
Headset
ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings
Rear hub
Alloy, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree Micro Engagement, four pawl, XD Driver, 32 hole
Front hub
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru axle, 32 hole
Spokes
Pillar 2.0mm, black stainless, brass nipples
Rims
WTB ST Tough i30 TCS 2.0 System, pinned joint, tubeless ready, 32 hole, 29in (front), 27.5in (rear)
Tyres
Schwalbe Magic Mary Radial 29 x 2.5in Trail, Super Soft (front); Schwalbe Magic Mary Radial 27.5 x 2.5in, Gravity casing, Soft (rear)
Shift levers
SRAM S200 Eagle Trigger MMX, 12 speed
Rear mech
SRAM S100 Eagle, Half-Mount, 12 speed
Cassette
SRAM XG-1275 Eagle, 10-52T, 12 speed
Chain
SRAM GX, 12 speed
Crankset
SRAM S200, direct mount 30T chainring, DUB, 165mm crank length, 55mm chainline
Bottom bracket
SRAM DUB, BSA, 73mm
Seatpost
TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop)
Seat
Whyte Custom
Bar
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide
Stem
Whyte, 35mm extension, 35mm bar bore
Grips
Whyte Enduro lock-on
Front brakes
TRP EVO Expert hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX
Rear brakes
TRP EVO Expert hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor
Brakes levers
TRP EVO Expert, MMX
