Frame
BIG.NINE CF5 III
-
Material
carbon
-
Wheelsize
29x2.4" max.
-
Axle standard
148x12mm
-
Bottom bracket standard
BSA
-
Frame size
S, M, L, XL, XXL
-
Color
SPLATTER PURPLE/BLACK (FLASH BCP)
-
Fork
Fox 32 SC Factory
-
Fork features
Air, 100mm suspension travel, Tapered, 2 Position Remote lockout, 44mm fork offset, 29x2.4" max. wheelsize
-
Brakes
Shimano XTR M9220 (2 piston)
-
Rotors
Shimano RT-CL900 (180mm)
-
Headset
Acros ICR MERIDA INTEGRATED neck (Upper and lower IPS sealing)
-
Handlebar
FSA SIC CF 1-piece cockpit (carbon, 760mm width, -7°, S/M/L:60 mm, XL: 80 mm)
-
Grip
MERIDA TEAM CC
-
Derailleur (r)
Shimano XTR M9250 (wireless, Shadow+ GS)
-
Shifters
Shimano XTR M9250 (wireless)
-
Seat post
FSA SL-K (carbon, 30.9mm diameter, 0mm setback)
-
Seat clamp
MERIDA EXPERT
-
Saddle
Prologo Scratch M5 PAS Nack (V-mount adapter)
-
Chain
Shimano XTR M9100
-
Crank
Shimano XTR M9200 (30 teeth, S/M: 170 mm, L/XL/XXL: 175 mm)
-
Freewheel
Shimano XTR M9200 (9-45t)
-
Bottom bracket
Shimano SM-BB93 (BSA, 24mm axle)
-
Wheelset
Reynolds Blacklabel 309 XC Pro (110x15mm width front hub, 148x12mm width rear hub, 30mm inner width, Centerlock, Shimano MS 12 Speed, carbon, Tubeless ready (tubeless tape and valves included), Lifetime warranty)
-
Tyre front
Maxxis Rekon Race (29x2.4" WT, tubeless ready, 3C MaxxTerra EXO)
-
Tyre rear
Maxxis Rekon Race (29x2.4" WT, tubeless ready, 3C MaxxTerra EXO)
-
Axles
MERIDA EXPERT TR (including removeable lever, 6/4mm allen key)
-
Approx. weight
9.1 kg (weighed at frame size M)
-
Max. weight
135 kg
