Frame
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts, chain stay kick stand mount
Fork
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, Post Mount with single eyelets for mudguards
Headset
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed catridge bearings and front entry for cables
Rear Hub
Alloy, cup and cone, double sealed cartridge bearings, 32 hole
Front Hub
Alloy, double sealed cartridge bearings, 12mm x 100mm thru-axle, 32 hole
Spokes
2.0mm, PG, black stainless, brass nipples
Rims
WTB STp I27 rims, 32 hole
Tyres
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead
Shift Levers
Shimano Deore 10 speed Rapidfire
Rear Mech
Shimano Deore 10 speed, Shadow design and direct attachment
Cassette
Shimano Deore 10 speed, 11-46T
Chain
Shimano Deore 10 speed
Crankset
Whyte alloy, 40T alloy chainring
Bottom Bracket
Shimano BSA, square taper, 122.5mm
Seatpost
Whyte 6061 alloy, 20mm offset, 350mm, two bolt clamp
Saddle
Whyte Custom
Handlebar
Whyte one piece bar and stem: 50mm extension, 720mm width, 20mm rise, seven degree backsweep, four degree upsweep
Stem
N/A
Grips
Whyte Custom dual density lock-on
Front Brake
Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor
Rear Brake
Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor
Brake Levers
Tektro T3020 Clean Sweep Design, three finger comfort lever
Pedals
Fibre reinforced composite platform
