Frame
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts, chain stay kick stand mount
Fork
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, Post Mount with single eyelets for mudguards
Headset
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed catridge bearings and front entry for cables
Rear Hub
Kynamic 250W, 36V, 45Nm 142mm power hub with replaceable freehub, 32 hole
Front Hub
Alloy, double sealed cartridge bearings, 12mm x 100mm thru-axle, 32 hole
Spokes
2.0mm, PG, black stainless, brass nipples
Rims
WTB STp I27 rims, 32 hole
Tyres
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead
Shift Levers
Shimano Cues 9 speed Rapidfire
Rear Mech
Shimano Cues 9 speed, Shadow Design and direct attachment
Cassette
Shimano Cues, 9 speed, 11-46T
Chain
Shimano Cues 9 speed
Crankset
Shimano Cues 9 speed, 170mm, 40T chainring, with chain guard
Bottom Bracket
Kynamic BSA, square taper, 122.5mm, with torque sensor
Seatpost
Whyte dropper post, 100mm drop
Saddle
Whyte Custom
Handlebar
Whyte one piece bar and stem: 50mm extension, 720mm width, 20mm rise, seven degree backsweep, four degree upsweep
Stem
N/A
Grips
Whyte Custom dual density lock-on
Front Brake
Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor
Rear Brake
Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor
Brake Levers
Tektro T3020 Clean Sweep Design, three finger comfort lever
Pedals
Fibre reinforced composite platform
Battery
250Wh internal battery
