Frame
6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts
Fork
Fox Float 38 Performance Elite, 160mm travel, 44mm offset with Grip X2 damper, tapered steerer, 110mm x 15mm Boost, E-thru-axle
Shock
Fox Float X Performance Elite DPS, EVOL LV, 230 x 57.5mm, custom tuned for Whyte
Headset
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings, with side entry internal routing
Rear Hub
DT Swiss Hybrid H1900, 12mm x 148mm Boost spacing, SRAM XD steel driver, 6 Bolt
Front Hub
DT Swiss Hybrid H1900, 110mm x 15mm Boost, 6 bolt
Spokes
DT Swiss elemental
Rims
DT Swiss Hybrid H1900
Tyres
Maxxis Assegai WT, TR, 29in x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead, front; Maxxis Minion DHR 2 WT, TR, 29in x 2.4in 120TPI, Double Down Casing, 3C MaxxTerra, Dual Compound, rear
Shift Levers
SRAM AXS Pod, right, MMX, 12 speed
Rear Mech
SRAM S1000 AXS Eagle, 12 speed
Cassette
SRAM XS 1275, T-Type, 10-52T, 12 speed
Chain
SRAM GX T-Type, 12 speed
Crankset
Whyte 155mm ISIS arms, SRAM Direct mount 36T chainring, T-Type
Seatpost
KS Vantage, 34.9mm, external 30mm adjustment, with Southpaw remote lever (150 drop (S), 170mm drop (M), 200mm drop (L&XL))
Saddle
Whyte Custom
Handlebar
Race Face Turbine Alloy Bar 35mm, 800mm, 35mm rise
Stem
Whyte, 35mm Extension, 35mm Bar Bore
Grips
Whyte Enduro lock-on
Front Brakes
Magura MT7, 1 finger lever, 203mm MDRC 6 bolt rotors
Rear Brakes
Magura MT7, 1 finger lever, 203mm MDRC 6 bolt rotors
Brake Levers
Magura MT7
Pedals
Fibre reinforced composite platform
Drive Unit
Bosch Performance Line CX (Smart System) Drive Unit with 85Nm maximum torque, 600W of peak power and 250W of nominal power. Features four power mode settings including Tour+ and eMTB.
Battery
Bosch PowerTube 800Wh, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. PowerMore compatible.
Display
Bosch System controller mounted within the top tube, paired with the discrete bar mounted Mini Remote. Also connects to the Bosch eBike Flow smartphone app to give you even more insight and control at your fingertips.
Charger
Charger 4A (230V)
