Frame
Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg
Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg
Stem
Tern Andros, adjustable, forged construction, patented technology
Headset
Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Grips
Ergon
Saddle
Tern GSD by Velo, with rear handle
Seatpost
Tern Telescope, 34.9/30.9 mm, 2014-AL
Front Brake
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
Rear Brake
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
Brake Levers
Magura MT5 e-stop, hydraulic, with brake sensor
Bell
Pitch Plus, brass
Front Hub
Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing
Rear Hub
Enviolo SP, 380% continuously variable range, Boost
Spokes
Stainless steel, 13G
Rims
Tern Atlas, ultra wide 36 mm, dual reinforced joint
Tyres
F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex
Shifter
Enviolo, Twist
Rear Derailleur
Enviolo Internal Hub Gearing
Crankset
Tern GSD custom, Gates CDX CNC machined beltring
Cassette
Gates CDX, precision CNC machined cog
Bottom Bracket
Motor integrated
Chain
Gates Carbon Drive CDX belt
Pedals
Urban with non-slip surface, sealed bearings
Motor
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery
Bosch 500 Wh
Display
Bosch Purion, 4 mode selectable, walk assist
Charger
220V, 4A (EU); 100-240V, 4A (US)
Kickstand
Atlas Lockstand, w/ remote unlock, patented technology
Front Light
Tern Valo Direct, 190 lumens
